Glass Lined Thin Film Evaporator Wiped Film Evaporator- TangLian Chemistry
Glass Lined Thin Film Evaporator Wiped Film Evaporator is a type of evaporator characterized by the film like flow of material liquid along the heating tube wall for heat transfer and evaporation. Its advantages are high heat transfer efficiency, fast evaporation speed, and short material residence time, making it particularly suitable for the evaporation of heat sensitive substances.
|
INNER VESSEL
|
JACKET
|
|
|
MATERIAL
|
Carbon Steel with Glass Linning
|
Carbon Steel
|
|
DESIGN PRESSURE
|
F.V.
|
-0.1/0.6Mpa
|
|
DESIGN TEMPERATURE
|
0 / 180
|
0/ 200
|
|
WORKING TEMPERATURE
|
0.8-2.0
|
|
Material structure
Material: Glass lined, stainless steel, etc
Glass Lined Thin Film Evaporator Wiped Film Evaporator Characteristics and advantages
1. Large evaporation area and high product efficiency
2. Short retention time of materials, difficult decomposition, pollution, and deterioration of compounds
Technical Parameters
|
Items
|
Specification
|
|
MATERIAL
|
Carbon Steel with Glass Linning
|
|
DESIGN PRESSURE
|
Atmospheric pressure
|
|
DESIGN TEMPERATURE
|
-19 / 200
|
|
GLASS LINED THICKNESS
|
0.8-2.0
|
Features and advantages
25 years of production experience, 30000㎡ factory scale, 100 million annual output value, 6000+ cooperative customers, 37+ countries covered.
Suitable for dilute solution concentration in pharmaceutical, food, chemical and other industries, with good corrosion resistance, durability, and compliance with pharmaceutical hygiene requirements.
Company Profile
Shandong Tanglian Heavy Industry Group Co., Ltd. is located in Zibo, an important modern industrial city in China. It is a well-known chemical and pharmaceutical equipment manufacturer in northern China. Shandong Tanglian Heavy Industry Group originated from Shandong Tanglian Chemical Equipment Co., Ltd., which was established in 1998 in Zibo City, the famous hometown of glass lining in China.
At present, the group branches Shandong Tanglian Chemical Equipment Co., Ltd., Binzhou Tanglian Chemical Machinery Co., Ltd., Shandong Tanglian Metal Products Co., Ltd., Shandong Tanglian Engineering Design Co., Ltd. and other subsidiaries. Shandong Tanglian Group now develops into a complete industrial chain integrating upstream chemical engineering design, equipment manufacturing and downstream installation and maintenance. The company has more than 20 years of experience in the production and design of various equipment such as chemical and pharmaceutical industries. Through continuous technology accumulation, it has developed related process packages and provided process design and equipment manufacturing services for thousands of domestic and foreign companies. The industry-related technologies have distinctive features,the advantages are obvious.
The group starts from the advantages with the basic principle of perfecting the global market service, plays an important role.
Shandong Tanglian Heavy Industrial Group , one of the longest established factories for Chemical reactors / Chemical vessels in China .
We have ISO , SGS , CE ,EU Welder Approval Test Certificate for our company , products and workers .
We mainly focus on below products
Chemical reactor , Storage / Receiving / Buffer tank
Column / Tower section , Pipe line
Heat exchanger / condenser , Evaporator
Main material of our equipment :
Glass Lining , PTFE,ETFE,PFA Lining
Stainless Steel , Carbon Steel , Hastelloy , DP Steel
FAQ
Reply: Yeah. we are a real factory of glass lined enquipment and stainless steel equipment. And our factory have over 20 years history. Welcome anytime.Question: What is the daily output of your equipment?
Reply: 1500sets per year.Question: How about your quality warranty?
Reply: We have strict inspection for the equipment before loading, and have one year quality warranty if the customers use the goods under the correct operation.Question: How about the MOQ? How about delivery time?
Reply:
01 MOQ: 1set
02 Delivery time in accordance with the production time,30-60 days to the port of departure.
